Siemens AG announces Dresser-Rand Acquisition

In a press release today, Siemens AG announced the intent by agreement to purchase all shares of issued and outstanding stock of Dresser-Rand at approximately $7.6 Billion USD. Based out of Houston Texas, USA, Dresser-Rand specializes in compressors and turbo machinery in the oil an gas industry. The company plans to maintain the ‘Dresser-Rand’ name and plug them into their Vision 2010 plans as their ‘Oil and Gas’ company, strengthening their turbo compressor and large steam turbine capabilities among many other strengths that Dresser-Rand brings to the table.

“Our aim is to become the leading rotating equipment and process system integrator for the oil & gas industry. Dresser-Rand has strong presence in oil and gas, a reputation for technology leadership and innovation, and a talented and experienced leadership team. Our intention is to leverage these strengths by maintaining the existing company and brand name and selectively moving complementary products and services from the existing Siemens portfolio into Dresser-Rand enabling us to offer a much broader range of products, services and solutions to meet our customers’ needs,” said Lisa Davis, member of the Managing Board of Siemens AG. (per Press Release)

This transaction is expected to benefit Siemens AG by at least 150 million Euro annually by 2019.

Dresser-Rand Purchased by Siemens AG

 Information shown herein was sourced from the press release above. Image shown courtesy of Dresser-Rand.

Design Highlights for August

NASA Develops Multi-Alloy 3D Printing Process – RT.com

August 3rd, 2014. image Researchers at NASA’s Pasadena based Jet Propulsion Lab are actively working with a process that 3D prints an object composed of more than one metal alloy. The team has been working on the project since 2010, after being inspired by wanting to improve on methods of combining parts made from different materials. The team has developed a method of changing the metal powder at will, and using a customized laser sintering process that adds layers tangentially on a rotating shaft. The article noted gradient alloy objects have been developed in the past, but not with definitive separate parts in a single mass. Some possible uses were proposed such as an object with different melting temperatures, densities and even magnetic properties.

Edit:

A far more detailed review was found at Design Engineering.com, discussing the linear process that has been developed, some drawbacks with brittleness and their workarounds. Additionally, Design Engineering pointed to the full scientific report on the radial deposit process.

The Diverging State of PDM – Lifecycle Insights

By Chad Jackson on Friday, March 28th, 2014. image I enjoyed reading Chad Jackson’s take on the changes that are taking place in the data management space especially after we did our look to 2015. Chad noted how the Product Data Management (PDM) across the industry began to more towards the cloud in a similar path, but sometimes different methodologies. The thing that was significant to all is that everyone was moving together in a common direction. However since 2013 things have begun to fragment, and Chad discusses specific examples of how this is starting to occur, and what the strategies are behind these diverging methodologies. I liked Chad’s statement here:

“This stands as the antithesis of Autodesk’s and Dassault Systèmes approach, which is the automate the manage and tracking of changes as much as possible. GrabCAD’s approach is to give the market what they want. The approach for Autodesk’s and Dassault Systèmes is to be more visionary. [SIC]“

Siemens CAE & Test Symposium 2014 – Siemens

“Smarter Decisions, Better Products” image Siemens has announced their CAE & Test Symposium that is planned for October 22-23, 2014 on a boat of all things – Queen Mary in Long Beach, California. This is the former NX CAE Symposium. Siemens has rebranded the symposium to reflect their expanded capabilities especially after the purchase of LMS International NV in 2012. This should represent the entire lineup of testing and simulation software under their roof. LMS, by the way, was a strategic acquisition and gave Siemens some well-regarded capabilities. Here is a quote from the Siemens 2012 press release: “Siemens will become the first product lifecycle management (PLM) software company to provide a closed-loop systems-driven product development solution extending all the way to integrated test management.” I’d really like to attend this symposium to see how they intent on moving forward with all the luggage they are now carrying.

The One True Part Number System – GrabCAD

By Ed Lopategui on August 5th, 2014. imageEd did a great job on this somewhat humorous write-up, looking at the differences between people’s (often heated) arguments over structured vs. non-structured part numbers. There is significant truth in both arguments, but Ed called for a balance and flexibility that allowed for things to work together. Some items he suggested are:

  • A temporary pool of simple numbers in early-stage design
  • Easy re-identification
  • Gaps in numbering to permit grouping
  • Numbers evolve as the design matures
  • Include only the minimum information, and decide how much that will be.

What is interesting is that these might be considered what GrabCAD has in the works for their Workbench service, which is rapidly evolving as we speak, and has a lot of eyes on it (including my own).

3Dconnexion announce their next device – SpaceMouse® Pro Wireless

SpaceMouse Pro Wireless ISO

Today 3Dconnexion have announced their next product, the 3Dconnexion SpaceMouse® Pro Wireless. Following on from the 3Dconnexion SpaceMouse® Wireless last September, this product is a natural progression for the Professional series of 3Dconnexion hardware range. At first glance little has changed, but its the thought put in under the hood, with a nod towards user experience and flexibility which make this new product worthy. While the 3Dconnexion SpaceMouse Wireless was visually a completely new product, essentially replacing the 3Dconnexion SpaceNavigator. The SpaceMouse Pro Wireless is a logical evolution of what isn’t an old product anyway, however, 3Dconnexion clearly state in their press release that the SpaceMouse Pro Wireless is “all-new”.

The all-new SpaceMouse Pro Wireless offers professional 3D performance without wires.

3Dconnexion is proud to announce the 3Dconnexion SpaceMouse Pro Wireless , the first wireless 3D mouse with a comprehensive selection of professional features.

I asked John Moseley, Director of Global Marketing at 3Dconnexion, if the design team had decided to stick with the original puck design (pre-SpaceMouse Wireless), or tweaked it since their last product release. Instead of solely answering that question, he came back to me with a number of details not found in the press release:

  • The SpaceMouse Pro Wireless puck design is basically the same with the exception of the silver ring, which is a feature of our Professional Series.

Apart from the obvious extra features (buttons, hand rest), there are a few differences vs. the SpaceMouse Wireless

  • Doubled the battery life by fitting a larger battery capable of two months of operation between charges (based on 8 hours per day, 5 days per week).
  • Extended wireless range – in optimum conditions the SMPW will work up to 20 metres away from the USB receiver. Optimum generally means the USB receiver is placed in the supplied USB hub and placed on the desktop (i.e. not hidden / obstructed under the desk).
  • Two extra items in the box. A nice Twin-port USB Hub and a 0.5m USB cable in addition to the standard 1.5m cable. The goal here is to give users flexibility in how / where they place the USB receiver and charge the product.
  • USB receiver storage hole – on the underside of the product we created a slot for the USB receiver to be placed in when the user is taking the product from A to B. You can see this on one of the images (the USB receiver is shown inserted in the hole).

SpaceMouse Pro Wireless bottomDedicated storage hole for the USB receiver

“With the SpaceMouse Wireless, the world’s first wireless 3D mouse, 3Dconnexion revolutionized the market. Now the SpaceMouse Pro Wireless raises the bar even higher, delivering the same wireless freedom to 3Dconnexion’s professional series of 3D navigation devices.”

Antonio Pascucci, vice president of products at 3Dconnexion.

SpaceMouse Pro Wireless benefits

  • Complete Wireless Freedom — 3Dconnexion 2.4 GHz wireless technology for a real-time connection to your digital content and a two-month battery life. When it does need recharging, simply connect one of the supplied USB cables and continue working.
  • Professional Performance — SpaceMouse Pro Wireless automatically recognizes your application and assigns commands to its four Intelligent Function Keys. Go one step further by assigning a four-section on-screen radial menu to any of the device’s 15 buttons—providing easy access to even more of your favorite commands.
  • Keep Your Eyes On What Matters — SpaceMouse Pro Wireless’s On-Screen Display provides a convenient on-screen reminder of the commands assigned to its Intelligent Function Keys, allowing you to focus on your designs—not a keystroke cheat sheet.
  • View Your Work From Every Angle  Detect errors, explore alternatives, and present your work more effectively for review with SpaceMouse Pro Wireless’s 6DoF navigation and QuickView Keys.
  • Minimize Hand Movements —Conveniently positioned keyboard modifiers provide quick and easy access to Control, Shift, Alt and Esc functions, reducing the time you spend moving your hand to the keyboard.
  • World-Class Ergonomics And Build Quality  The SpaceMouse Pro Wireless has a full size, soft-coated hand rest for maximum comfort. Each of its 15 tactile, fully programmable buttons are perfectly positioned for maximum efficiency. Furthermore, it’s packaged into an expert design built with the highest quality components.

3Dconnexion USB-Hub Right-Iso_Receiver

  • Flexible Connectivity  Either plug the USB receiver directly into your workstation or use the Twin-port USB Hub (included as standard). With a choice of two USB cables, it’s easy to connect and charge SpaceMouse Pro Wireless whatever your desktop setup.
  • The 3Dconnexion Experience – 3DxWare® 10 allows you to customize and optimize your SpaceMouse Pro Wireless for peak performance. Easily tailor settings and buttons to your application and needs. Take advantage of exciting new features. Design, create and navigate in brave new ways.

SpaceMouse Pro Wireless top_02Are you ready to go pro? Click here to find out everything you need to know about SpaceMouse Pro Wireless today.

Pricing and Availability

SpaceMouse Pro Wireless will be available in early July. Check the 3Dconnexion website or local resellers for pricing.

About 3Dconnexion

3Dconnexion’s 3D mice revolutionize the way people interact with 3D applications, providing a more natural and intuitive way to interact with digital 3D content. 3Dconnexion 3D mice provide an intuitive, balanced and cooperative work style that results in increased productivity, improvements in creativity and enhanced comfort.

Supported by today’s most popular and powerful 3D applications, 3Dconnexion’s award-winning 3D mice serve a wide variety of industries and are used by engineers, designers, architects and artists across the globe.

Stay up-to-date with all the latest company and industry news via the 3Dconnexion blog, Facebook and Twitter.

Imagery Courtesy of 3Dconnexion.

[subscribe2]

BricsCAD V14 Now Supports 3Dconnexion 3D Mice

BricsCAD-regular-horizontalBricsCAD V14 now supports 3Dconnexion® 3D mice, the premier 3D navigation devices for engineers, architects and 3D professionals. BricsCAD, that offers all the familiar .dwg CAD features and 3D Direct Modeling, now got even more powerful. Users can simultaneously pan, zoom and rotate 2D/3D content while the standard mouse is free to select menu items or parts of the model.

Highlights of BricsCAD’s 3D mouse integration include:

  • Intelligent 3D Navigation — The 3D mouse automatically follows the point of interest to continuously determine the optimal center of rotation. When combined with 3Dconnexion’s patented 6-degrees-of-freedom navigation, users benefit from the most natural 3D navigation experience ever.
  • Multiple 3D Navigation Modes — Including Object, Helicopter, Camera and Target Camera modes, enabling the user to customize the 3D mouse experience to their workflow.
  • 2D Navigation Mode — 3Dconnexion 3D mice also deliver value in BricsCAD’s 2D modes by allowing users to simultaneously pan and zoom the worksheet.

“We are excited to introduce 3Dconnexion 3D mouse support in BricsCAD V14,” says Erik De Keyser, CEO of Bricsys. “We have delivered a rich 3D mouse integration, that provides smooth and intuitive navigation across 2D and 3D workflows, complementing our goal to enable modeling and designing at unmatched speed.”

BricsCAD V14 supports the entire line of 3Dconnexion 3D mice, including the new 3Dconnexion SpaceMouse® Wireless, the world’s first wireless 3D mouse.

Says Erik De Keyser: “3Dconnexion devices give users the ability to navigate their 3D world with more precision, speed and efficiency—improving designs and the design experience as a whole. We’re excited to now bring that functionality to BricsCAD V14.”

About 3Dconnexion

3Dconnexion’s 3D mice revolutionize the way people interact with 3D applications, providing a more natural and intuitive way to interact with digital 3D content. 3Dconnexion 3D mice provide an intuitive, balanced and cooperative work style that results in increased productivity, improvements in creativity and enhanced comfort.

Supported by today’s most popular and powerful 3D applications, 3Dconnexion’s award-winning 3D mice serve a wide variety of industries and are used by engineers, designers, architects and artists across the globe. 3Dconnexion’s European headquarters are in Munich, Germany with offices worldwide. Stay up-to-date with all the latest company and industry news via the 3Dconnexion blog, Facebook and Twitter.

About Bricsys

Bricsys® is a global provider of dwg engineering design software brought to market under the BricsCAD® brand. With relentless commitment to the success of the BricsCAD community, Bricsys is focused on providing an industrial strength CAD software platform and industry leading support at a compelling price to customers in the AEC, GIS, civil engineering, process and power, and mechanical CAD markets. Founded in 2002, Bricsys is a founding member of the Open Design Alliance.

For more information visit www.bricsys.com.

[subscribe2]

Luxion Unleash KeyShot 5

keyshot5-whats-new-1080If Luxion had stores around the world, then on May 29, 2014, I’m confident they would have had people queuing up outside kipping in their sleeping bags, amping to get their mitts on their shiny new copy of KeyShot 5. It’s one of those applications that is just plain cool. The Luxion team do a fantastic job of making people lust after it, but really, it’s about the customers who use it and make sure they let the world know how brilliantly it JUST WORKS. I personally haven’t had the opportunity to use this tool yet, but Luxion have hooked Design and Motion up with a fully functional 30 day trial, so we will set about kicking its tires in due course.

The main point of this post is to let our readers know about its release if you didn’t already and inform you we have a review underway. Anyway, here’s some blurb from Luxion if you guys haven’t read it already:

With Luxion rendering technology bringing faster rendering speed and capabilities, creating images, animations and interactive visuals throughout the product development process has never been easier. KeyShot 5 introduces enhanced usability and pro level features that allow engineers, designers and 3D professionals to make their workflow more efficient and take their visuals to the next level.

Overview

With KeyShot 5, we wanted to make the interface that revolutionized 3D rendering and animation even more simple to use with new ways to share resources, faster ways to work with materials, more powerful animation features and advanced capabilities.

The KeyShot Cloud leads features with the ability to download new resources and share custom assets. With this, a more streamlined interface delivers a completely updated user experience, smoother interaction of materials and options, a new Ribbon menu for common tools, Favorites and advanced material display. Rendering workflow enhancements introduce Instancing, ability to retain textures, seven new procedurals and speed increases for rendering large models. Animation users gain more power with the introduction of Fade Animation, Motion Blur and Events, while Pro users will receive NURBS ray-tracing, HDRI Editor updates with a new Sun & Sky System, Perspective matching and output to common 3D printer formats.

whats_new_perspective_matching

KeyShot 5 Features

The entire list of features in KeyShot 5 can be seen and downloaded in a What’s New guide that includes information on how each feature works. Visit keyshot.com/whats-new/. A video of the new features can be viewed here. Highlights include:

whats_new_keyshot_cloud_ssKeyShot Cloud
The KeyShot Cloud is the online library where users can download new resources, and share their own custom assets. Opening the KeyShot Cloud enables easy drag-and-drop downloading of new resources into their local KeyShot Library, and quick search features and filters to find the perfect resources for a scene. All resources remain on a user’s computer with a copy of the resource uploaded to the KeyShot Cloud and no scene or personal info stored online. The KeyShot Cloud is accessible directly from inside KeyShot and online at cloud.keyshot.com.

whats_new_nurbsNURBS Ray-tracing
NURBS ray-tracing delivers more accurate geometry with smoother edges. This new import feature gives users the option to import and render NURBS geometry from their favorite 3D modeling application. The advantage is crisper visuals and smaller file sizes over data imported as triangle that can display edges and gaps on close detail shots. NURBS import is currently available for all geometry formats, including Creo, CATIA, Inventor, NX, Rhino, SolidWorks, Solid Edge, STEP, IGES, Parasolid and ALIAS. Available with KeyShot Pro versions.

whats_new_patternInstancing
Instancing allows users to duplicate parts in KeyShot and on import without increasing file size. Instancing of parts is available within KeyShot as a Pattern tool and completely automated in select KeyShot plugins. All instances can be treated separately for quick appearance studies or linked to apply materials quickly, but will all update when LiveLinking or update geometry is used.

whats_new_fade_animationFade Animation
The new Fade animation allows users to quickly apply an animation that fades parts from one opacity level to another. Through KeyShot Animation users add individual transforms that add animations with a click of a button instead of managing keyframes. Just as simple, Fade animations can be applied while adjusting the opacity of parts and groups on-the-fly which allows users to see the update in real-time as animations are created. Available with the KeyShot Animation Add-on.

whats_new_sun_skySun & Sky System
KeyShot 5 introduces a new Sun & Sky system for automatic creation of physically accurate geographic lighting. Preset resolutions and locations together with day selection, time and turbidity sliders allow the creation of unlimited daylight scenarios. Custom Sun & Sky environments can be created by users as well and combined with other lighting options available in the KeyShot HDRI Editor. Available with KeyShot Pro versions.

Availability

KeyShot 5 is available immediately. Pricing starts at $995 US. As with previous versions, animation capabilities can be added to KeyShot for $500 US and interactive KeyShotVR capabilities can be added for $1000 US.

All customers who bought KeyShot on or after February 14th, 2014, as well as all customers who purchased KeyShot for Education will receive the upgrade to KeyShot 5 free of charge. All KeyShot customers with active annual maintenance will automatically receive the upgrade to KeyShot 5. All other customer can upgrade to KeyShot 5 for an incremental fee.

For more information please contact sales@luxion.com. For more information on KeyShot 3D rendering, animation and KeyShotVR please visit www.keyshot.com.

[subscribe2]

Solid Edge ST7 Enhancements at Solid Edge University 2014

Solid Edge unveiled their improvements in the upcoming ST7 software release as well as initiatives that the company has been working towards. They have continued to show clear focus on their customer’s needs and included 1300 user requests that spanned the entire scope of the Solid Edge product.

Solid Edge ST7 Microsoft Surface Pro

The power of Solid Edge ST7 modeling and drafting can be experienced on Microsoft Surface Pro devices.

The Solid Edge team’s presentation of ST7 was themed in four parts:

Accelerate your 3D modeling

Part to Sheet Metal:

Wrap sheet metal parts around solid part faces with corner treatments (this has some really good potential)

Blank Body:

Amazing analysis and flat patterning tool to deal with difficult stamped features. This performs a meshed surface body analysis along with the material properties of the shape to accurately deconstruct the component into a flat sheet model.

3D Measure:

  • Multiple measurements from single command
  • Easy to read graphical measurements
  • Built-in automatic note-pad

Standards based holes:

  • Specify bolt size and fit for correct size of hole
  • Widespread international standards support

Solid Edge University 2014 Presentation Hole Enhancements

Draft:

  • Drafting had some really nice improvements.
  • Dynamic drawing view display for all view types
  • Associative Annotations (this is great)
  • Parts List component highlights and thumbnail views
  • Streamlined individual part or sub-assembly view creation
  • Automatic coordinate dimensioning and jogging

Solid Edge University 2014 Presentation Draft

Solid Edge University 2014 Draft Tool-tips in Parts List

Duplicate Component:

New patterning method that allows automatic intelligent orientation based on existing similar locations in model.

Solid Edge University 2014 Presentation Duplicate Component

Peer Locate:

  • Design in-context at any level
  • Inter-part links without write access to upper level assembly

3D Sketch:

  • Available in Part, Assembly, and Sheet Metal environments
  • Faster Design of 3D-swept components

Photo-realistic rendering:

Solid Edge ST7 Keyshot Engine Rendering(via embedded Keyshot functionality; license required)

All Solid Edge face styles and view transferred

Solid Edge University 2014 Presentation Keyshot

Additional enhancements include:

  • New Start-up screen with easy access to common tasks
  • Enhanced tooltips with embedded videos
  • Parts catalog
  • Fixed length curve holds length of swept components while they remain flexible (doesn’t sound like much but delivers a really cool functionality for standardized tubes and the like)
  • Enhanced frame design with up 2X faster workflows
  • An Insert component button (Good)
  • Pattern of a Pattern recognition
  • Materials table was completely overhauled and rebuilt
  • Quick Shape Primitives
  • One-button update in assemblies
  • Improved sketch feedback
  • Pattern components along a curve
  • Enhanced Face relate
  • Simplified Assemblies honored
  • Simulation enhancements

And more….

Streamline Your Design Management

Streamlined design management in Solid Edge SP (Microsoft Sharepoint  management)

Solid Edge University 2014 Presentation Solid Edge SP

More on this to come in the near future.

Power Up With New Apps

Enjoy Amazing User Experience

My Thoughts

These enhancements were all requested by users to meet the needs that they experience in production. This was the second time I was involved in the discussions relating to what features people desired and how they were being implemented in the software. We literally sat down and said, “this is what we want”. Solid Edge’s lead developer asked how they wanted that to work, took notes, and we all voted on the top items. It’s really cool to see the developments happen as quickly as they do at Solid Edge.

Solid Edge University 2014 Wish List Voting

Microsoft Surface & Keyshot Engine Rendering Images courtesy of Siemens PLM Software

[subscribe2]
